Rekon 4 LR Micro Long Range Quad Analog Version

HGLRC Rekon4 Long Range Quad Analog FPV Racing Drone F722 Mini Flight Controller 28A 4in1 ESC 1603 Motor VTX Zeus 800mW

Brand Name:Rekon4 FPV Racing Drone 4S Version
Net Weight:164.9g(Without receiver)

Rekon4 Freestyle Frame
Type:4" frame
Wheelbase:182mm
Support for propellers:Up to 4 inches
Overall size:192 * 136mm

Zeus F722 mini Flight Controller
MPU:BMI270
CPU:STM32F722 RET6
Input Voltage:3-6S Lipo
BEC Output:5V/3A,9V/2A

Zeus 28A BL_S 3-6S 4in1 ESC
CPU:EFM8BB21F
Input Voltage:3-6S Lipo
Steady Current:28A
Peak Current:35A（10 Sec）

Zeus 800mW VTX
Output power:PIT/25/100/200/400/800mW
Input:DC 6-26V
Antenna:MMCX

Caddx Ratel2 FPV Camera
Image Sensor:1/1.8 " 1200TVL CMOS
Input Power:DC 5-40V
Dimensions:19mm*19mm*20mm

1603 2800KV Brushless Motor
No.of Cells(Lipo):16.8 V (4S)
Recommended Prop(inch):4 Inches

M80 GPS
Power Supply:5V
Size:18.5mm x 18.5mm x 7.1mm

Soter FPV Drone Buzzer
Input voltage: 5V
Size:22mm x 12mm x12mm

GEMFAN 4024 4 Inch 2-Blades Propeller
Quantity:2 CW & 2 CCW

GEMFAN F4019 4 Inch 2-Blades Propeller
Quantity:2 CW & 2 CCW

Package Includes:
1x Rekon4 Frame
1x F722 Mini Flight Controller
1x 28A BL_S 3-6S 4in1 ESC
1x Zeus VTX 800mW
1x Caddx Ratel2 FPV Camera
4x 1603 2800KV Motors
1x M80 GPS
1x Soter FPV Drone Buzzer
4x GEMFAN 4024 Propeller
4x GEMFAN F4019 Propeller
1x SMA Inner needle Small hammer antenna (RHCP)
2x Battery Straps
1x TPU Naked GoPro Mount
1x GoPro Bracket
1x Receiver（Optional）

Recommended Battery:
4S:750mAh-850mAh
