Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version
Rekon 6 Mini Long Range Quad Analog Version

Rekon 6 Mini Long Range Quad Analog Version

$289.99
DESCRIPTION



Rekon 6

Concept


This six-inch platform is an adaptation of the Rekon 5 to match the new light 6ÔÇŁ t-mount props that now entered the market. The main advantage of 6" compared to the 5" version is the ability to carry even higher loads, especially large four cell 21700 Lithium-Ion packs with over 4000mAh for extreme flight times. With its 1500kV 2105.5 motors the quad can be run on 6S for increased power, but it is mainly intended as an ultra-high efficiency cruiser on 4S.

Frame Design
The Rekon 6 features an innovative frame design using single-piece front and rear arms locked by an aluminium bolt. The bolt is used to create a strong and stiff center section of the frame, locking the arms and de-coupling forces from the rest of the frame. This allows the use of use very light M2 hardware and thin carbon plates on the other parts of the frame, reducing the overall weight for maximum efficiency. On top of that, the bolt makes it possible to apply much more torque and it's not prone to break or strip like M2 or M3 hardware often does. A lot of attention was also put toward the design of the front and camera mount. Dead cat frames are inherently prone to take heavy impacts in this area since the arms are swept backward and the front is exposed. This is why the Rekon 6 uses a flexible, 3D printed canopy supported by a carbon brace to absorb impact energy and protect the camera in case of a crash.

Key Features
- Lightweight frame with 10mm aluminium bolt construction, compact 25/20mm standoff split deck main body for double 20x20 stacks
- Shock absorbing TPU front with integrated GoPro mount
- Foldable crossfire immortal T-mount inspired by Alexandre Arvinte (@ledrone.club)
- Mild dead cat design reducing the props in view while not affecting flight performance
- Optional braces for improved vibration dampening and crash resistance
- Optimized for 2105.5 and 2303 motors with 12x12 M2 mounts
- GPS mount for M80 GPS
- External buzzer mount for Soter Buzzer

Specifications

Rekon 6 LR FPV Drone F722 mini Flight Controller 28A 4in1 ESC Rekon 2105.5 Motor Zeus 800mW VTX

Brand Name:Rekon6 LR
Net Weight:242.6g(without receiver)

Rekon LR 6 inch Frame
Type:6 inches frame
Wheelbase:242mm
Support for propellers:Up to 6 inches
Overall size:235 * 178mm

Zeus F722 mini Flight Controller
MPU:MPU6000
Input Voltage:3-6S Lipo
BEC Output:5V/2A,9V/1A

Zeus 28A BL_S 3-6S 4in1 ESC
Input Voltage:3-6S Lipo
Steady Current:28A
Peak Current:35A´╝ł10 Sec´╝ë

Zeus 800mW VTX
Output power:PIT/25/100/200/400/800mW
Input:DC 6-26V
Antenna:MMCX

Caddx Ratel 2 FPV Camera
Image Sensor:1/1.8 " 1200TVL CMOS
Input Power:DC 5V
Dimensions:19mm*19mm*20mm

Rekon 2105.5 1500KV Motor
No.of Cells(Lipo):16.8 V (4S)
Recommended Prop(inch):6 Inches

M80 GPS
Power Supply:5V
Size:18.5mm x 18.5mm x 7.1mm

Soter FPV drone buzzer
Input voltage: 5V
Size:22mm x 12mm x12mm

GEMFAN 6026 6 Inch 2-Blades Propeller
Quantity:4 CW & 4 CCW

Package Includes:
1x Rekon6 LR Frame
1x Zeus F722 mini Flight Controller
1x Zeus 28A BL_S 4in1 ESC
1x Zeus VTX 800mW
1x Caddx Ratel 2 FPV Camera
4x Rekon 2105.5 1500KV Motors
1x M80 GPS
1x Soter FPV drone buzzer
8x GEMFAN 6026 Propeller
1x SMA Mini Hammer Antenna (RHCP)
2x Battery Straps
1x TPU naked Gopro mount
1x Receiver´╝łOptional´╝ë

Recommended battery:
4S:1000mAh-1500mAh

18650 lithium-ion battery



Download Manual here
